Sports function performance test system (1D-lite)

KWFP4035-SA2

A high-performance portable measurement system designed specifically for biomechanics research that can accurately measure dynamic indicators such as X/Y/Z triaxial force and torque.

Made of high-rigidity lightweight alloy plate, it has 4 built-in high-precision force sensors and an integrated high-performance data acquisition system.The overall structure is strong and lightweight, making it easy to flexibly deploy in laboratories and outdoor venues.Supports wide-band dynamic measurement, which can satisfy both static load analysis and high-speed dynamic mechanical feature acquisition.It provides professional solutions for various sports technology analysis, gait research and equipment testing, and is an ideal mobile measurement platform in the field of biomechanics research.

Online Consultation

Downloads

Features
Parameters
Application
Related Products

Features

Portable design
The compact and lightweight structure combines mobility and stability for installation. It can quickly complete equipment deployment in laboratories or outdoor sites, and achieve seamless switching between fixed and mobile test modes.
Accurate dynamic measurement
It uses advanced three-dimensional force decoupling technology to ensure high accuracy of mechanical measurements, and has high-frequency sampling capabilities, which is suitable for precise analysis in dynamic processes.
Synchronous linkage acquisition
It realizes multi-device collaboration, supports flexible networking configuration, ensures high-precision data synchronization acquisition of multiple force platform systems, and meets the needs of collaborative work in complex testing scenarios.
Precise timing control
Compatible with the synchronization trigger function of external devices to improve the timing consistency of each link of the experiment. It is suitable for scenarios with high-precision synchronization requirements such as gait research and motion analysis.
Long-lasting battery life
Innovative dual-mode power supply design and built-in high-capacity battery support long-term outdoor operation, solving the testing problems in power-free environments and greatly expanding the range of experimental site choices.
Customized service system
We provide personalized customization solutions from hardware configuration to software functions, and carry out special optimization according to users' special needs to ensure that the equipment is perfectly matched with various research objectives.

Parameters

size	mm	400 x 350
weight	Kg	5.5
thickness	mm	30
How it works	/	Resistance strain gauge
Number of sensors	/	4
Range	F/N	5000

Overload	%FS	20
Accuracy	%FS	≤0.3
Sampling resolution	Hz	1000
Protection level	/	IP52
Operating temperature	℃	-20~60
Communication interface	/	Bluetooth
